CyaNitrate wrote:-the Hyperion pre kills the signal when turned all the way down (counterclockwise) -the Bit pre seens backwards...full counterclockwise is full-bore and it mellows as it goes clockwise
All normal!
Thanks Pal! Gonna add an order switching switch, then on to finishing!
jwar wrote:BRO! There is only one order! Bass>fuzz>fuzz>fuzz>fuzz>overdriven amp.
goroth wrote:Come up here and fuzz party. Yes. Fuzz party. It is a legit verb.
I had the exact same problem with the DC jack, otherwise everything seems to be working fine with my build. I wanted to make sure though is radio station bleed in normal? This isn't really an issue for me, but I wanted to make sure that this isn't something to troubleshoot later on.
For the radio bleed, I get that on my Fuzz Face clone and a modded MXR Dynacomp. Most likely a transistor is picking up a signal.
I had a question for the Hyperion build, for the 2N2907A that is going in Q4, I understand the tab is facing the dot, but the Q4 space has 4 holes while the transistor has 3 legs. Which hole does the "middle" leg of the transistor go in?
My hyperion doesn't work probably because its an incredibly sloppy build on my part I fixed the issue I described above but it doesn't work Gonna take out the board and try and troubleshoot it and then redo it all, maybe try my vfm
Derelict78 wrote:That probably sounds awful in the best possible way.
wimacfee55 wrote:For the radio bleed, I get that on my Fuzz Face clone and a modded MXR Dynacomp. Most likely a transistor is picking up a signal.
I had a question for the Hyperion build, for the 2N2907A that is going in Q4, I understand the tab is facing the dot, but the Q4 space has 4 holes while the transistor has 3 legs. Which hole does the "middle" leg of the transistor go in?
With the tab facing the dot, the hole closest to the dot is vacant i believe. you shouldn't have to bend any of the legs far, they should line up nicely. You should be able to push the body of the transistor down nearly flush to the board, with out any legs being in between the body and the board, if that makes sense.
jwar wrote:BRO! There is only one order! Bass>fuzz>fuzz>fuzz>fuzz>overdriven amp.
goroth wrote:Come up here and fuzz party. Yes. Fuzz party. It is a legit verb.
my vintage fuzz master works!!!! i think i have done it right, but what is it meant to sound like with the switch down? i get a buttload of subs and not much else
stoked that this one turned out well, it's given me the confidence to troubleshoot my hyperion and maybe try more project in the near future! thanks devi team <3
Derelict78 wrote:That probably sounds awful in the best possible way.
ThurberMingus wrote:I can't seem to find any kits in the Devi store. When will they be back Mrs. Aen?
It'll be a while...We have a few other big projects that are taking up our time right now, but we might offer another round in a few months.
Fair warning, though, if we do them again they won't be $35. We spent a lot of time drilling boxes and putting the kits together for this round, way more than I expected.
goosekevin wrote:my vintage fuzz master works!!!! i think i have done it right, but what is it meant to sound like with the switch down? i get a buttload of subs and not much else
stoked that this one turned out well, it's given me the confidence to troubleshoot my hyperion and maybe try more project in the near future! thanks devi team <3
With the switch down it should be the VFM. With the swich up should be what used to be called "chaos" mode. But with the recent changes with the 2 electrolytic caps it behaves differently. More like a VFM noise floor with both switches engaged with the extra volume and white noise component.
psparrow wrote:I had the exact same problem with the DC jack, otherwise everything seems to be working fine with my build. I wanted to make sure though is radio station bleed in normal? This isn't really an issue for me, but I wanted to make sure that this isn't something to troubleshoot later on.
Many devi pedals will pick up some radio in certain settings. which circuit did you build?
